Product Overview

The LSB series vertical sand pumps are specially developed drilling fluid transfer pumps for specific installation requirements. They are suitable for transporting corrosive drilling fluids with suspended particles or other similar liquid media under similar working conditions. They are mainly used for situations with limited installation space, special occasions, and as feed for centrifuges. Currently, there are six categories: LSB8*6, LSB8*5 (specifically designed for Daqing), LSB6*5, LSB5*4, LSB4*3, and LSB3*2, with a total of 50 specifications. They can also be used in 50Hz and 60Hz power grids as needed.

Product features

Aesthetically pleasing: The overall structure is vertical, elegant and imposing, with a small footprint

High efficiency: The impeller and pump casing flow channels adopt the most optimal streamlined design

Long service life: The impeller and the flowing fluid are made of high wear-resistant cast iron.

No blockage: The open impeller design is adopted.

No leakage: A combined composite seal consisting mainly of mechanical seals and auxiliary gland seals is used. The mechanical seals are made of hard alloys, and their service life is 5 times that of ordinary mechanical seals.
